Product Overview: It comes with an SFP+ 20-pin connectorfor hot-swappable functionality. The digitaldiagnostic function can be realizedthrough l2C. lt has a built-in dual clock andData Recovery (CDR)

Product Overview: The transceiver consists of two parts: a high-performance 1270nm DFB laser. Transmitter and high sensitivity PIN integrated with TIA. The receiver. The module is hot-swappable to a 20-pin connector. The high-speed electrical interface is based on low-voltage logic and has a nominal 100 ohm differential impedance and AC coupling in the module. Optical output can be disabled by TX_Disable LVTTL logical high level input. Signal loss (RX_LOS) output is used to indicate the loss of the receiver's input optical signal. The transceiver does not use the receiver RATE_SELECT pin. 2-wire interfaces (SCL, SDA) for serial ID, digital diagnostics, and other control/monitoring functions.

Product Overview: It is a very compact 10.3125Gb/s optical transceiver module for serial optical communication applications, supporting data rates of 10.3125Gbps (10GBASE-ZR) and transmission distances of up to 80 km on SMF.
